UL2651 flat ribbon cable with PVC insulation, UL-recognized and rated 105°C/300V. Flexible, durable, and safe wiring for computers, control panels, and industrial machinery.


UL2651 Flat Ribbon Cable – 300V 105°C PVC-Insulated Cable for Internal Wiring Applications

UL2651 is a UL-recognized flat ribbon cable designed for internal wiring in electronic and electrical equipment. Rated for 300V and operating temperatures up to 105°C, it features durable Polyvinyl Chloride (PVC) insulation, ensuring reliable performance across various applications.

This cable is ideal for scenarios demanding dependable low-voltage connections and durability, such as control panels, computers, and industrial machinery. Its flat design offers flexibility in routing while adhering to stringent safety standards.


 Key Features

  • Voltage Rating: 300V

  • Temperature Rating: 105°C

  • Conductor Sizes: 36 AWG to 14 AWG, solid or stranded

  • Conductor Material: Bare or tinned copper

  • Insulation: Extruded PVC

    • Minimum Average Thickness: 9 mils

    • Minimum Thickness at Any Point: 7 mils

  • Flame Resistance: Passes UL VW-1 and CSA FT1 Flame Tests

  • Standards Compliance: UL 758 AWM Style 2651

  • Environmental Compliance: RoHS & REACH Compliant


Applications

  • Internal wiring of electronic and electrical equipment

  • Control panels and industrial machinery

  • Computers and peripherals

  • Point-to-point wiring in meters and instrumentation

  • IDC (Insulation Displacement Connector) applications

UL2651 cable is engineered to deliver consistent performance in various environments, offering flexibility, durability, and compliance with safety standards.
