UL10938 XLPE Insulated Wire
UL10938 single-conductor wire with XLPE insulation, UL-recognized and rated 105°C/600V. Provides heat resistance, voltage stability, and flame performance for industrial wiring.
UL10938 XLPE Insulated Wire – 105°C / 600V Industrial-Grade Internal Wiring Solution
UL10938 is a UL-recognized single-conductor wire insulated with extruded cross-linked polyethylene (XLPE). Rated for 105°C and 600V, this wire is designed for internal wiring in industrial equipment, control panels, and electrical assemblies requiring strong heat resistance, voltage stability, and flame performance.
Key Features
Conductor: Solid or stranded, bare or tinned copper, available from 34 AWG to 4/0 AWG
Insulation: XLPE with a minimum average thickness of 7 mils (0.18 mm) and a minimum thickness at any point of 5 mils (0.13 mm)
Temperature Rating: Up to 105°C
Voltage Rating: 600V
Flame Resistance: Meets horizontal flame test requirements
Standards: UL 758 (AWM Style 10938)
Usage: Internal wiring for electrical equipment and assemblies
Common Applications
Internal wiring for industrial machinery and equipment
High-voltage routing inside control panels and power distribution boxes
Environments demanding heat resistance, voltage stability, and flame retardancy
Wiring for electronic devices and industrial automation systems
