UL20942

UL20942 flat ribbon cable with PVC insulation, UL-recognized and rated 105°C/300V. Flexible, durable, and safe wiring solution for appliances, control panels, and industrial machinery.

UL20942 Flat Ribbon Cable – 300V 105°C PVC-Insulated Cable for Internal Wiring Applications

UL20942 is a UL-recognized flat ribbon cable designed for internal wiring in electronic and electrical equipment. Rated for 300V and operating temperatures up to 105°C, it features durable Polyvinyl Chloride (PVC) insulation, ensuring reliable performance across various applications.

This cable is ideal for scenarios demanding dependable low-voltage connections and durability, such as control panels, appliances, and industrial machinery. Its flat design offers flexibility in routing while adhering to stringent safety standards.

Key Features

Voltage Rating: 300V
Temperature Rating: 105°C
Conductor Sizes: 24 AWG to 18 AWG, solid or stranded
Conductor Material: Bare or tinned copper
Insulation: Extruded PVC
- Minimum Average Thickness: 10 mils
- Minimum Thickness at Any Point: 9 mils
Assembly: Two to three conductors laid parallel
Flame Resistance: Passes UL VW-1 Flame Test
Standards Compliance: UL 758 AWM Style 20942
Environmental Compliance: RoHS & REACH Compliant

Applications

Internal wiring of electronic and electrical equipment
Control panels and industrial machinery
Appliances requiring reliable internal connections
Point-to-point wiring in meters and instrumentation

UL20942 cable is engineered to deliver consistent performance in various environments, offering flexibility, durability, and compliance with safety standards.
