UL21283 Hook-Up Wire
UL21283 low-voltage cable with XLPE insulation, UL-certified for internal wiring in electronics, control panels, and assemblies. Ensures thermal stability and reliability.
UL21283 Hook-Up Wire – 30V 80°C XLPE-Insulated Multi-Conductor Cable
UL21283 is a UL-certified low-voltage cable designed for internal wiring in electronic devices, control panels, and electrical assemblies. It features cross-linked polyethylene (XLPE) insulation, offering enhanced thermal stability, electrical reliability, and space-efficient construction.
Key Features
Rated Temperature: 80°C
Rated Voltage: 30V
Conductor: Stranded or solid, bare or tinned copper
Insulation: Cross-linked polyethylene (XLPE)
Flame Test: UL VW-1 and CSA FT1 compliant
Standards: UL758, UL1581, CSA C22.2 No.210
Common Applications
Internal wiring for electronic devices and home appliances
Control circuits in industrial and automation systems
Multi-conductor cable assemblies in compact enclosures
Use in environments requiring high flexibility and thermal resistance
