UL21352 multi-conductor cable, 30V and 75°C rated, with FRPE jacket and AWM insulation, offers flexible, flame-resistant wiring for electronic equipment.


UL21352 FRPE Insulated Cable – 75°C / 30V Multi-Conductor Wire for Internal Electronic Applications

UL21352 is a UL-certified multi-conductor cable designed for internal wiring of electronic equipment. Rated for 75°C and 30V, this cable features solid or stranded copper conductors, insulation complying with the manufacturer's AWM procedure, and an extruded FRPE jacket. It complies with the VW-1 vertical flame test under UL 758 AWM standards, making it suitable for applications requiring flexibility and flame resistance.


Key Features

  • Conductor: Solid or stranded copper, 30 AWG to 4/0 AWG

  • Insulation: Labeled or complies with manufacturer's AWM Procedure

  • Assembly: Two or more insulated singles twisted together

  • Shield: Optional

  • Jacket: Extruded FRPE

  • Temperature Rating: 75°C

  • Voltage Rating: 30V

  • Flame Resistance: Passes VW-1 vertical flame test

  • Standard: UL 758 AWM Style 21352

  • Application: Internal wiring of electronic equipment


Applications

  • Internal wiring in electronic devices

  • Signal transmission in computers and peripherals

  • Control wiring in industrial equipment

  • Applications requiring flexible and flame-retardant wiring solutions

External Technical Reference

UL iQ™ Style Page – UL21352
