UL21089 multi-conductor cable, 600V 75°C with FRPE insulation, offers flexibility, flame resistance, and reliable wiring performance.


UL21089 – 600V / 75°C Multi-Conductor Cable with FRPE Jacket for Industrial and Electronic Applications

UL21089 is a UL-certified multi-conductor cable designed for both internal and external wiring of electronic equipment. Rated for 600V and 75°C, this cable features solid or stranded copper conductors, flame-retardant FRPE (Flame Retardant Polyethylene) insulation, and complies with the Cable Flame Test under UL 758 AWM standards. It is suitable for applications requiring flexibility and flame resistance.


 Key Features

  • Conductor: Solid or stranded copper (30 AWG to 4/0 AWG)

  • Insulation: PVC, PE, SRPVC, PP, Foam-PE, or FRPE

  • Jacket: Extruded FRPE (Flame Retardant Polyethylene)

  • Temperature Rating: 75°C

  • Voltage Rating: 600V

  • Flame Resistance: Passes UL VW-1, FT1, and FT2 tests

  • Standards: UL 758, UL 1581, UL 2556

  • Compliance: RoHS, REACH, CE

  • Application: Internal and external wiring of electronic equipment


Applications

  • Internal wiring in electronic devices

  • External connections in industrial control systems

  • Circuits requiring flame resistance and insulation durability

  • High-reliability internal and external cabling for sensitive systems
