UL21266 multi-conductor cable, 600V and 180°C rated, with FRPE insulation and jacket, delivers durable, high-temp, flame-resistant external wiring


UL21266 FRPE Insulated Cable – 600V / 180°C Multi-Conductor Wire for External Electronic Applications

UL21266 is a UL-certified multi-conductor cable designed for external wiring in electronic equipment. Rated for 600V and 180°C, this cable features solid or stranded copper conductors, FRPE insulation, and an extruded FRPE jacket. It meets UL 758 Appliance Wiring Material (AWM) standards and passes the Cable Flame Test, making it ideal for high-temperature, flame-resistant external wiring.


 Key Features

  • Conductor: Solid or stranded round copper, 40 AWG and larger

  • Insulation: FRPE, compliant with manufacturer’s AWM procedure

  • Assembly: Two or more insulated conductors, twisted or cabled, may include shielding, fillers, and barrier layers

  • Jacket: Extruded FRPE (min. avg. thickness 12 mils, min. at any point 10 mils)

  • Temperature Rating: 180°C

  • Voltage Rating: 600V

  • Flame Test: Passes UL Cable Flame Test

  • Standard: UL 758 AWM Style 21266

  • Application: External appliance and equipment wiring requiring thermal durability and flame resistance


Applications

  • External wiring in high-temperature electronic systems

  • Industrial control panel interconnections

  • Flame-retardant circuits in appliances and automation systems

  • External cables in demanding environments requiring durability

 External Technical Reference

UL iQ™ Style Page – UL21266
