UL21120

UL21120 cable, 600V 80°C with FRPE insulation, provides flexibility, flame resistance, and reliable wiring for electronic equipment.


UL21120 – 600V / 80°C Multi-Conductor Cable with FRPE Jacket for Flexible and Spiral Applications

UL21120 is a UL-certified multi-conductor cable designed for both internal and external wiring of electronic equipment. Rated for 600V and 80°C, this cable features solid or stranded copper conductors, flame-retardant FRPE (Flame Retardant Polyethylene) insulation, and complies with the Cable Flame Test under UL 758 AWM standards. It is suitable for applications requiring flexibility and flame resistance.


 Key Features

  • Conductor: High-purity tinned or bare copper strands (36 AWG and larger)

  • Insulation: AWM-compliant material

  • Jacket: Flame-retardant polyethylene (FRPE)

  • Temperature Rating: 80°C

  • Voltage Rating: 600V

  • Dielectric Strength: 2000Vac for 60 seconds without breakdown

  • Spark Voltage: 3KV

  • Flame Resistance: Passes UL VW-1, FT1, and FT2 tests

  • Standard: UL 758 AWM Style 21120

  • Application: Internal and external wiring of electronic equipment


Applications

  • Internal wiring in electronic devices

  • External connections in industrial control systems

  • Circuits requiring flame resistance and insulation durability

  • High-reliability internal and external cabling for sensitive systems
