UL21551 multi-conductor cable, 30V and 80°C rated, with PVC insulation and optional shield, offers flexible, flame-resistant low-voltage wiring.


UL21551 PVC Insulated Cable – 80°C / 30V Multi-Conductor Wire for Internal Electronic Wiring

UL21551 is a UL-certified multi-conductor cable designed for the internal wiring of electronic equipment. Rated for 80°C and 30 Vac , this cable features solid or stranded copper conductors, PVC insulation, and may include an optional shield and jacket. It complies with the Cable Flame Test under UL 758 AWM standards, making it a reliable choice for low-voltage signal and control wiring.


Key Features

  • Conductor: Solid or stranded copper

  • Insulation: PVC

  • Jacket: Optional

  • Shielding: Optional (foil or braid)

  • Temperature Rating: 80°C

  • Voltage Rating: 30 Vac

  • Flame Resistance: Passes Cable Flame Test

  • Standard: UL 758 AWM Style 21551

  • Application: Internal wiring of electronic equipment


Applications

  • Signal wiring inside electronic devices

  • Low-voltage control circuits

  • Consumer electronics and compact instruments

  • Wiring requiring slim and flame-rated construction

External Technical Reference

UL iQ™ Style Page – UL21551
