UL1431 hook-up wire with XLPVC insulation, UL-recognized and rated 105°C/600V. Durable, flexible, and safe wiring solution for appliances, control panels, and industrial machinery.


UL1431 Hook-Up Wire – 600V 105°C XLPVC-Insulated Wire for Internal Wiring Applications

UL1431 is a UL-recognized single-conductor hook-up wire designed for internal wiring in electronic and electrical equipment. Rated for 600V  and operating temperatures up to 105°C, it features durable Cross-Linked Polyvinyl Chloride (XLPVC) insulation, ensuring reliable performance across various applications.

This wire is ideal for scenarios demanding dependable high-voltage connections and durability, such as control panels, appliances, and industrial machinery. Its design offers flexibility in routing while adhering to stringent safety standards.


Key Features

  • Voltage Rating: 600V

  • Temperature Rating: 105°C

  • Conductor Sizes: 24 AWG to 4 AWG, solid or stranded

  • Conductor Material: Bare or tinned copper

  • Insulation: Extruded XLPVC

    • Minimum Average Thickness: 9 mils

    • Minimum Thickness at Any Point: 7 mils

  • Flame Resistance: Passes UL VW-1 Flame Test

  • Standards Compliance: UL 758 AWM Style 1431

  • Environmental Compliance: RoHS & REACH Compliant


 Applications

  • Internal wiring of electronic and electrical equipment

  • Control panels and industrial machinery

  • Appliances requiring reliable internal connections

  • Point-to-point wiring in meters and instrumentation

UL1431 wire is engineered to deliver consistent performance in various environments, offering flexibility, durability, and compliance with safety standards.
