UL10958
UL10958 PVC hook-up wire, UL-recognized and rated 105°C/600V. Provides flexible, flame-resistant, and reliable internal wiring for electronic devices, control systems, and industrial equipment.
UL10958 Hook-Up Wire – 600V for Electronic Equipment
UL10958 is a UL-recognized single-conductor wire designed for the internal wiring of electronic and electrical devices. Rated for 600 volts and up to 105°C, this wire features PVC (Polyvinyl Chloride) insulation, offering dependable performance in demanding industrial and commercial environments.
Its construction supports a wide range of conductor sizes and is suitable for applications requiring flexibility, flame resistance, and long-term insulation stability.
Key Features
Voltage Rating: 600V AC/DC
Temperature Rating: 105°C
Conductor Sizes: 30 AWG to 10 AWG
Conductor Type: Bare or tinned copper, solid or stranded
Insulation: Extruded PVC
Min. Avg. Thickness: 9 mils
Min. Thickness at Any Point: 8 mils
Flame Test: UL Horizontal Flame Test
Certifications: UL 758 AWM Style 10958
Environmental Compliance: RoHS & REACH compliant
Applications
Internal wiring in appliances and control panels
Power and signal transmission in industrial machinery
General-purpose wiring in instrumentation systems
Automotive and HVAC module connections
