SXL

SXL automotive wire with heavy-wall XLPE insulation, rated -40°C to +125°C. Delivers heat, oil, and abrasion resistance for engine, battery, and heavy-duty vehicle wiring.


SXL Automotive Wire

HEAVY-WALL XLPE INSULATED CABLE

Insulation Material
Cross-linked Polyethylene (XLPE)
Temperature Range
-40°C to +125°C
Conductor
Stranded Bare Copper
Key Features
Heavy-wall, High-temp resistance
Resistance
Oil, Abrasion & Chemical Resistant
Application
Heavy-Duty Platforms & Engine Compartments

Key Features

ENGINEERED FOR HEAVY-DUTY USE

Operating Temp
-40°C to +125°C
Voltage Rating
Up to 60V
Insulation
XLPE (Heavy-Wall)
Conductor
Stranded Bare Copper
Compliance
SAE J1128, Ford M1L-85B, Chrysler MS-5919

Applications

HEAVY-DUTY CONNECTIVITY SOLUTIONS

  • Engine compartments and battery cables: Designed for heavy-duty vehicle requirements
  • Automotive power distribution: Reliable for high-load circuits
  • Control panels: Proven for trucks, buses, and off-road machinery
  • Industrial & Agricultural: Durable wiring for demanding field equipment
  • Harsh conditions: High-temperature and oil-resistant routing

SXL wire's rugged construction and thermal resilience make it the preferred choice for demanding OEM and aftermarket applications, where durability and electrical performance are essential.

Mechanical & Thermal Properties

SAE J1128 TESTING STANDARDS

SAE Cable TypeMin. Tensile (MPa)Min. Tensile (psi)Min. Elongation (%)Test Temp (°C)Temp Class (°C)
TWP / GPT / HDT11160012511080
STS / HTS7100015011080
TXL / GXL / SXL101500150155125
TWE / GTE / HTE111600200150120

* Note: The above accelerated aging temperatures are appropriate for insulating materials currently specified in this standard.
