GPT Automotive Wire
PVC INSULATED CABLE FOR GENERAL PURPOSE
Insulation Material
Polyvinyl Chloride (PVC)
Temperature Range
-40°C to +80°C
Conductor
Stranded Bare Copper
Voltage Rating
Up to 60V DC
Compliance
SAE J1128 Standard
Application
Dashboards & Signal Systems
Key Features
STANDARD WALL PVC AUTOMOTIVE WIRE
Temperature Rating
-40°C to +80°C
Voltage Rating
60V DC / 25V AC
Insulation
PVC (Chemical & Abrasion Resistant)
Circuit Identification
Available in Multiple Colors
Compliance
SAE J1128 Standard
Applications
GENERAL-PURPOSE AUTOMOTIVE CONNECTIVITY
- Dashboard wiring: Reliable connections for interior lighting and instrumentation
- Control modules: Used for signal harnesses and control systems
- Low-voltage systems: Optimized for standard vehicle electrical architectures
- General harness building: Suitable for widespread automotive wire harnessing
GPT wire is a dependable choice for standard automotive circuits where flexible, low-voltage, and chemically resistant wire is required.
Mechanical & Thermal Properties
SAE J1128 TESTING STANDARDS
| SAE Cable Type | Min. Tensile (MPa) | Min. Tensile (psi) | Min. Elongation (%) | Test Temp (°C) | Temp Class (°C) |
|---|---|---|---|---|---|
| TWP / GPT / HDT | 11 | 1600 | 125 | 110 | 80 |
| STS / HTS | 7 | 1000 | 150 | 110 | 80 |
| TXL / GXL / SXL | 10 | 1500 | 150 | 155 | 125 |
| TWE / GTE / HTE | 11 | 1600 | 200 | 150 | 120 |
* Note: The above accelerated aging temperatures are appropriate for insulating materials currently specified in this standard.
